All types hydraulic hoses s are available in HYRUBBERS. The item SAE 100 R3 is on hot sale, please visit our website to see more information.
Size: 3/16"–1 1/4”
Working pressure: 105bar–26bar
Lenght: 50m/100m
Weight: 0.16–1kg/m
SAE 100 R3
APPLICATION: petroleum base and water base hydraulic fluids
INNER TUBE: Oil resistant synthetic rubber
REINFORCEMENT: two layers of high strength fiber braided
COVER: Abrasion, ozone, and weather resistant synthetic rubber
SURFACE: wrapped surface,smooth surface
WORKING TEMPERATURE: 40℃ (-104℉ ) to +100℃(+212℉)
SPECIFICATION:
DN | Hose I.D | Hose O.D | Working Pressure | Burst Pressure | MIN B.R | Weight | Length | |||
inch | mm | mm | MPa | psi | MPa | psi | mm | kg/m | metres | |
5 | 3/16″ | 4.8 | 12.7 | 10.5 | 1520 | 42 | 6500 | 75 | 0.16 | 50/100 |
6 | 1/4″ | 6.4 | 14.3 | 8.7 | 1350 | 34.8 | 5300 | 75 | 0.19 | 50/100 |
8 | 5/16″ | 7.9 | 17.5 | 8.4 | 1300 | 33.6 | 5200 | 100 | 0.26 | 50/100 |
10 | 3/8″ | 9.5 | 19 | 7.8 | 1200 | 31.2 | 4840 | 100 | 0.28 | 50/100 |
13 | 1/2″ | 12.7 | 23.8 | 7 | 1080 | 28 | 4340 | 125 | 0.4 | 50/100 |
16 | 5/8″ | 15.9 | 27 | 6.1 | 945 | 24.4 | 3780 | 140 | 0.55 | 50/100 |
19 | 3/4″ | 19 | 31.8 | 5.2 | 800 | 20.8 | 3220 | 150 | 0.69 | 50/100 |
25 | 1″ | 25.4 | 38 | 3.9 | 600 | 15.6 | 2420 | 205 | 0.82 | 50 |
32 | 1.1/4" | 31.8 | 44.4 | 2.6 | 40 | 10.4 | 1610 | 250 | 1 | 20-40 |
HOSE PHOTO:
PACKING AND LOADING:
WHY CHOOSE US?
●17+ years experience in rubber hydraulic hose and pvc hose industry.
●Main products: hydraulic hose, welding hose, oil hose, suction hose, etc.
●Located in Qingdao,China, closed with the seaport
●32 steel braiding machine, 2 sprial machine for 4 wire hoses, and 2 cotton braiding machine
●Outstanding R&D engineers team.
●OEM available.
●Consistent and well trained team.
●Experienced sales team for different markets.
●ISO9001 approved production process.
MARKET:
Based on products and services,Continuously optimize and improve enterprise management and technology.Committed to eliminating errors or defects in hose production process.
To create more value-added products for our partners Customer groups that have served already involve many countries and regions in the world.
